About
Description
Degrees of Freedom:
- Total Joints: 31
- Single Leg: 6
- Single Arm: 7
- Waist: 3
- Head: 2
Construction Materials:
- Aircraft-grade aluminum
- Titanium alloy
- High-strength engineering plastics
Actuators & Torque:
- Arm Joint Maximum Torque: 120 N·m
- Leg Joint Maximum Torque: 360 N·m
- Arm Maximum Payload: Peak: ~15 kg; Rated: ~7 kg
Power & Endurance:
- Battery Capacity: 15Ah (0.972 kWh)
- Battery Voltage: 75.6 V
- Battery Life: Approximately 3 hours
Computing & Sensing:
- Compute Module: Up to Jetson AGX Thor (2070 TOPS)
- Sensors: Humanoid binocular camera with a wide field of view
- Voice Interaction: Array microphone and high-power speaker
- Connectivity: WiFi 6, Bluetooth 5.2
Cooling System:
-
Local air cooling
Software & Development:
- OTA Updates: Yes
- Secondary Development: Yes
| Height x Width x Depth (Standing): 1820 x 456 x 218 mm |
| Weight with Battery: Approx. 70 kg |
| Total Degrees of Freedom (Joint Motors): 31 |
| Single Leg DOF: 6 |
| Single Arm DOF: 7 |
| Waist DOF: 3 |
| Head DOF: 2 |
| Dexterous Hand: Multiple models available |
| Bionic Head/Face: Yes |
| Joint Output Bearings: Industrial-grade cross-roller bearings (high precision, high load capacity) |
| Joint Motors: Low-inertia high-speed internal rotor permanent magnet synchronous motors (enhanced response speed and heat dissipation) |
| Maximum Arm Joint Peak Torque: 120 N·m |
| Maximum Leg Joint Peak Torque: 360 N·m |
| Maximum Arm Payload: Peak: Approx. 15 kg; Rated: Approx. 7 kg |
| Lower Leg + Thigh Length: 1045 mm |
| Forearm + Upper Arm Length: 690 mm |
| Main Materials: Aerospace-grade aluminum + titanium alloy + high-strength engineering plastics |
| Cooling System: Air-cooled |
| Power Supply: Low-resistance premium lithium battery |
| Battery Capacity: 15 Ah (0.972 kWh) |
| Battery Voltage: Maximum 75.6V |
| Base Computing Power: PC1: Intel Core i5 (Platform Functionality) PC2: Intel Core i7 (User Development) |
| Perception Sensor: Wide-Field-of-View Humanoid Binocular Camera |
| Voice Interaction: Array Microphone with High-Power Speaker |
| WiFi 6, Bluetooth 5.2: Supported |
| PC3 and PC4 slots are empty by default, supporting optional high-performance computing boards (up to 2 units, similar to B2 slot format) |
| 1 x Charger, 1 x Smart Battery (Quick-release) |
| 1 x Handheld Remote Controller |
| Operating Time: Approx. 3 hours |
| Smart OTA Updates: Supported |
| Secondary Development: Supported |
| Warranty Period: 12 months |
| The default configuration includes a protective bracket |
Description
Degrees of Freedom:
- Total Joints: 31
- Single Leg: 6
- Single Arm: 7
- Waist: 3
- Head: 2
Construction Materials:
- Aircraft-grade aluminum
- Titanium alloy
- High-strength engineering plastics
Actuators & Torque:
- Arm Joint Maximum Torque: 120 N·m
- Leg Joint Maximum Torque: 360 N·m
- Arm Maximum Payload: Peak: ~15 kg; Rated: ~7 kg
Power & Endurance:
- Battery Capacity: 15Ah (0.972 kWh)
- Battery Voltage: 75.6 V
- Battery Life: Approximately 3 hours
Computing & Sensing:
- Compute Module: Up to Jetson AGX Thor (2070 TOPS)
- Sensors: Humanoid binocular camera with a wide field of view
- Voice Interaction: Array microphone and high-power speaker
- Connectivity: WiFi 6, Bluetooth 5.2
Cooling System:
-
Local air cooling
Software & Development:
- OTA Updates: Yes
- Secondary Development: Yes
| Height x Width x Depth (Standing): 1820 x 456 x 218 mm |
| Weight with Battery: Approx. 70 kg |
| Total Degrees of Freedom (Joint Motors): 31 |
| Single Leg DOF: 6 |
| Single Arm DOF: 7 |
| Waist DOF: 3 |
| Head DOF: 2 |
| Dexterous Hand: Multiple models available |
| Bionic Head/Face: Yes |
| Joint Output Bearings: Industrial-grade cross-roller bearings (high precision, high load capacity) |
| Joint Motors: Low-inertia high-speed internal rotor permanent magnet synchronous motors (enhanced response speed and heat dissipation) |
| Maximum Arm Joint Peak Torque: 120 N·m |
| Maximum Leg Joint Peak Torque: 360 N·m |
| Maximum Arm Payload: Peak: Approx. 15 kg; Rated: Approx. 7 kg |
| Lower Leg + Thigh Length: 1045 mm |
| Forearm + Upper Arm Length: 690 mm |
| Main Materials: Aerospace-grade aluminum + titanium alloy + high-strength engineering plastics |
| Cooling System: Air-cooled |
| Power Supply: Low-resistance premium lithium battery |
| Battery Capacity: 15 Ah (0.972 kWh) |
| Battery Voltage: Maximum 75.6V |
| Base Computing Power: PC1: Intel Core i5 (Platform Functionality) PC2: Intel Core i7 (User Development) |
| Perception Sensor: Wide-Field-of-View Humanoid Binocular Camera |
| Voice Interaction: Array Microphone with High-Power Speaker |
| WiFi 6, Bluetooth 5.2: Supported |
| PC3 and PC4 slots are empty by default, supporting optional high-performance computing boards (up to 2 units, similar to B2 slot format) |
| 1 x Charger, 1 x Smart Battery (Quick-release) |
| 1 x Handheld Remote Controller |
| Operating Time: Approx. 3 hours |
| Smart OTA Updates: Supported |
| Secondary Development: Supported |
| Warranty Period: 12 months |
| The default configuration includes a protective bracket |
Unitree
by
Unitree
Unitree H2 EDU Humanoid Robot
- Regular price
- $68,900.00
- Sale price
- $68,900.00
- Regular price
-
Shipping calculated at checkout.
Providing the best new Tech Experience, Energy Independence and Robotics Ways of Optimisation
Providing the best new Tech Experience, Energy Independence and Robotics Ways of Optimisation
Couldn't load pickup availability
Packaging note:
Equipment is being supplied in a manufacturer packaging
