Effort Tech EFT Z20 Standard V3.0 G20 with RTK Drone Kit includes the following items:
- Effort Tech EFT Z20 Standard V3.0 G20 with RTK Drone - 1 pc
- 14S 7200W Charger - 1 pc
- 14S 20000mAh Drone Battery - 3 pcs
Please note: The kit is in demo condition and has never been flown.
New Upgrade · Solo Flight
DRONE KIT
EFT Z20 Standard V3.0 G20 with RTK
Smart and Agile — Easier Solo Operation for Precision Agriculture
20L
Spray Tank
51.5kg
Max Takeoff Weight
15 L/min
Max Flow Rate
2km
Transmission Range
Flexible Impeller Pump — Precise Flow Control
Modular design with efficient cooling delivers smooth, consistent flow with strong chemical compatibility and easy maintenance — stable spraying whether you're running high or low dose applications.
Modular Flight Control System — Stronger Protection, Safer Operation
The PMU, FMU, and RTK module are independently plugged in, each with dedicated protection for enhanced stability and safety. A separated CAN bus design provides multi-channel data transmission for stable, reliable communication.
PMU, FMU, and RTK separately housed for maximum stability.
Independent Avionics Module
Multi-channel bus ensures uninterrupted, reliable communication.
Separated CAN Design
New Motor System — Robust Power, Efficient Cooling
An integrated injection-molded motor mount allows easy, level-free installation. Built-in cooling fans dissipate heat efficiently, while the separated ESC-motor design simplifies maintenance. Waterproof connectors ensure long-term reliability in the field.
No calibration or leveling needed.
Injection-Molded Motor Base
Convenient maintenance, lower repair costs.
Separated ESC & Motor
Stable performance on long-duration flights.
High-Efficiency Cooling Fan
Dustproof, waterproof, and reliable.
High-Safety Connectors
Improved Structure — Extreme Details, Enduring Durability
Die-Forged Structure: High-density aluminum alloy — compact and solid.
Anti-Off Arm Buckle: Dual-lock, shock-resistant for safe flight.
High-Current PDB: Copper busbar, higher overcurrent capacity, lower heat.
Injection-Molded Plugs: Waterproof, dustproof, and wear-resistant.
Application in Multi-Agri — One for All, Precise and Efficient
The upgraded flexible impeller pump delivers smooth flow, strong chemical compatibility, and easy maintenance for stable spraying across high and low dose applications. Paired with an intelligent centrifugal nozzle featuring adjustable angle and fine atomization, plus an all-in-one quick-swap module to meet diverse agricultural needs.
Precise obstacle avoidance, safely navigates different obstacles.
4D Precision Radar
High-brightness headlight safeguards night operations.
80W Drone Headlight
1080P camera for a wide, clear field view.
HD Gimbal Camera
EFT Flight Assistant — Smarter Flight, Smoother Control
A 7-inch large-screen remote with customizable buttons for flexible operation. The upgraded EFT Flight Assistant app offers optimized functions and remote OTA updates for smarter, more convenient control.
Large Screen
Historical Work Reports
Route Adjustment
Map Rectification
OTA Upgrades
Rigorous Testing, Reliable Quality
Rigorously tested for waterproofing, corrosion resistance, and temperature extremes to ensure stable operation in harsh field conditions.
Technical Specifications — Z20P
Weight parameters vary by ±1 kg depending on configuration and craft.
Weight (without battery) |
23.5 kg |
Weight (with battery) |
31.5 kg |
Max Takeoff Weight |
51.5 kg |
Wheelbase |
1737 mm |
Number of Axes |
Four-axis |
Unfolded Size |
2355 × 2276 × 707 mm |
Folded Size |
622 × 813 × 719 mm |
Flight Time (no load) |
17 min |
Flight Time (full load) |
7 min 40 s |
MOTOR SYSTEM | |
Model |
E9-L/9620 |
Motor Size |
104 × 51 mm |
KV / Voltage |
80KV / 54V |
Rated Power |
1440 W |
Propeller |
43 inch, nylon mixed with carbon |
SPRAY SYSTEM | |
Tank Capacity |
20 L |
Nozzle Type |
Centrifugal nozzle |
Spray Width |
4–8 m |
Atomized Particle Size |
50–500 μm |
Max Flow |
15 L/min |
SPREAD SYSTEM (optional module) | |
Tank Capacity |
30 L |
Applicable Particle Size |
0.5–6 mm (dry granules) |
Spread Width |
8–10 m |
REMOTE CONTROL | |
Display Screen |
7 inch |
Transmission Distance |
2 km (open area, 2.5 m altitude) |
Battery Runtime / Charging Time |
4–6 h / 3.5 h |
Operating Temperature |
0–40°C |
POWER SYSTEM | |
Battery Spec. |
14S 20000mAh |
Battery Weight |
8 kg |
Charger Input / Output |
AC100–240V 50/60Hz / DC20–62V |
Charging Current |
Max. 100A |
Charger Weight |
10 kg |
