Which Steering Column Flange Does Your Tractor Need?
- The steering column flange is the mechanical connection between the XAG APC automated steering wheel and your tractor's column — the wrong type means the autopilot can't be installed at all.
- The XAG APC flange range covers the steering column profiles of most major tractor and harvester brands used in precision agriculture across a wide variety of spline configurations.
- Not sure which type fits your machine? Share your tractor make, model, and year with our team — we'll identify the correct spline type before you order so there are no returns or delays.
There are no products in this collection yet
FAQ
1
What is a steering column flange and why do I need it?
The steering column flange is the adapter that connects the XAG APC automated steering wheel to your tractor's existing steering column:
- Mechanical link: It attaches the APC steering wheel directly onto your tractor's column spline — replacing the original steering wheel during autopilot operation.
- Spline-specific: Every tractor steering column has a specific spline profile — the flange must match exactly for a secure fit.
- Required for installation: Without the correct flange, the APC steering wheel cannot be mounted. It is a mandatory component for any APC installation.
2
How do I know which spline type fits my tractor?
The spline type depends on your tractor's steering column specification:
- Check your tractor manual — the steering column spline type is usually listed under technical specifications or steering system components.
- Contact your tractor dealer — they can confirm the column spline profile for your specific make, model, and year.
- Ask our team — share your tractor make, model, and year and we'll identify the correct flange type from our compatibility database before you order.
- Why it matters: Ordering the wrong type means the flange won't fit the column — always confirm before purchasing.
3
What's the difference between the spline types — A, B, C, and so on?
Each letter corresponds to a different spline geometry:
- Spline count: Different types have a different number of teeth around the shaft.
- Spline diameter: The outer and inner diameter of the spline profile varies between types.
- Tooth profile: The shape and depth of each tooth differs — even flanges that look similar externally may not be interchangeable.
- Practical result: Two flanges from different letter types will not fit the same column — the spline type must match your tractor exactly.
4
Are these flanges compatible with both APC1 and APC2?
Compatibility varies by flange type:
- Most flanges are APC1-specific — designed for the original APC1 AutoPilot Console steering wheel.
- Spline type F is compatible with both APC1 and APC2 — it is the only dual-compatible option in the current range.
- APC2 users: If you're installing an APC2, confirm compatibility with our team before ordering.
5
Can I install the flange myself, or do I need a technician?
Installation is designed to be straightforward:
- No drilling or fabrication — the flange slides onto the steering column spline and secures with the included fasteners.
- Standard tools — a torque wrench and basic hand tools are sufficient for installation.
- APC mounting follows — once the flange is fitted, the APC steering wheel attaches directly onto it via the standard APC mounting interface.
- Recommended: If you're installing an APC for the first time, our team offers onboarding support — including setup guidance and first-field calibration assistance.
