Description
Ultimate Purge-Saving Multi-Material 3D Printing
Bambu Lab H2C Vortek Ultimate Bundle
The complete H2C multi-material configuration, combining the revolutionary Vortek Hotend Change System with two AMS 2 Pro units, one AMS HT and additional dedicated hotends. Designed to unlock the full automatic hotend-swapping capability of the H2C, the Ultimate Bundle delivers advanced multi-color printing with minimal purge waste and flexible engineering-material workflows.
7 Hotends
Full automatic active hotend workflow
2 × AMS 2 Pro
Eight standard AMS filament slots
1 × AMS HT
High-temperature filament management
350°C
Maximum nozzle temperature
Why Choose the Vortek Ultimate Bundle
Unlock the Full Potential of the H2C
The Vortek Ultimate Bundle expands the standard H2C Combo with an additional AMS 2 Pro, an AMS HT and extra hotends. This configuration allows the automatic material systems to feed both sides of the H2C toolhead and provides the hardware needed to fully utilize the six-position Vortek hotend changer.
Full Vortek Hotend Setup
Six interchangeable induction hotend positions work together with the fixed left hotend for fast, automated multi-material printing.
Minimal Purge Waste
Instead of repeatedly purging a single nozzle, Vortek swaps entire hotends and can keep individual materials associated with dedicated nozzles.
Two AMS 2 Pro Units
Eight automatically managed filament slots supply the Vortek side with a broad selection of colors and materials.
AMS HT Included
A dedicated high-temperature material system provides filament drying up to 85°C and feeds the fixed left-side hotend.
Extra Hotends Included
Additional 0.4 mm induction hotends and dedicated left-side 0.2 mm and 0.6 mm hotends expand the available tool configuration.
Up to 24 Filaments
The H2C platform supports expanded AMS configurations with up to 24 filament positions for advanced multi-color and multi-material jobs.
Vortek Hotend Change System
Six Automatically Swappable Induction Hotends
The Vortek system stores up to six interchangeable induction hotends inside the printer. When a different material is required, the H2C automatically parks the active hotend, selects another one and heats it through induction technology.
Intelligent Hotend Management
Dedicated Hotends for Specific Materials
Each induction hotend can retain filament information, allowing the H2C to remember previous filament-to-hotend assignments. The system can automatically suggest efficient combinations for future print jobs, reducing unnecessary purging and material handling.
Dual AMS 2 Pro
Eight Automatically Managed Filament Slots
The Ultimate Bundle includes two AMS 2 Pro systems. Each unit contains four filament slots, providing eight automatically managed spool positions for colors, support materials and engineering filaments.
4 + 4 Filament Slots
Two AMS 2 Pro systems provide eight filament positions for automatic loading, unloading and material switching.
65°C Filament Drying
AMS 2 Pro actively dries compatible filament with heated airflow at temperatures up to 65°C.
Automatic Spool Rotation
Filament spools rotate during drying to promote more even moisture removal throughout the roll.
RFID Filament Sync
Compatible Bambu Lab RFID filament is automatically recognized and synchronized with the printing system.
AMS HT
High-Temperature Filament Drying up to 85°C
The included AMS HT provides a dedicated filament path for demanding and moisture-sensitive materials. Its high-temperature drying system reaches up to 85°C and combines active moisture removal, sealed storage and intelligent filament feeding.
85°C Drying
High-temperature drying supports demanding engineering filaments that require intensive moisture removal.
Dedicated Left-Nozzle Feed
In the Ultimate configuration, AMS HT can supply the fixed left hotend while the two AMS 2 Pro units supply the Vortek hotends.
Multi-Material Printing
Up to Seven Materials with Minimal Purging
With six Vortek hotends and the fixed left nozzle, the H2C can combine up to seven colors or compatible materials in a single job while dramatically reducing the flushing required by conventional single-nozzle multi-material systems.
High-Speed Performance
Fast Motion with Closed-Loop Servo Extrusion
H2C combines a high-performance CoreXY motion system with a permanent-magnet synchronous servo extruder. The closed-loop system continuously monitors extrusion resistance and position, helping detect grinding and clogging while maintaining stable high-flow printing.
Engineering Materials
350°C Nozzles and 65°C Active Heated Chamber
Hardened-steel extrusion components, nozzle temperatures up to 350°C, a build plate capable of reaching 120°C and an actively heated chamber up to 65°C provide controlled conditions for a wide range of standard and engineering-grade materials.
Intelligent Monitoring
AI-Assisted Error Detection
Cameras and sensors monitor the filament path, toolhead and build area. H2C can identify abnormal extrusion behavior, filament problems and potential print failures while automatic pre-print checks help verify that the machine is ready before each job.
Technical Specifications
Bambu Lab H2C Vortek Ultimate Bundle
Build Area & Printing
| Printing Technology | Fused Deposition Modeling (FDM) |
| Single Nozzle — Left | 325 × 320 × 325 mm³ |
| Single Nozzle — Right | 305 × 320 × 325 mm³ |
| Dual-Nozzle Build Volume | 300 × 320 × 325 mm³ |
| Total Two-Nozzle Workspace | 330 × 320 × 325 mm³ |
| Motion System | CoreXY |
| Build Plate | Textured PEI flexible steel plate |
Toolhead & Temperature
| Vortek Positions | 6 interchangeable induction hotends |
| Fixed Hotend | 1 left-side standard hotend |
| Extruder Gear | Hardened steel |
| Nozzle Material | Hardened steel / stainless steel depending on size |
| Maximum Nozzle Temperature | 350°C |
| Supported Nozzle Diameters | 0.2 mm, 0.4 mm, 0.6 mm and 0.8 mm |
| Maximum Heatbed Temperature | 120°C |
| Maximum Chamber Temperature | 65°C |
Vortek System
| Automatic Hotend Change | Supported |
| Interchangeable Hotend Positions | 6 |
| Maximum Active Material Paths | 7 including fixed left hotend |
| Induction Heating | Supported |
| Approximate Induction Heat-Up | 8 seconds under specified conditions |
| Contactless Power & Communication | Supported |
| Hotend Filament Memory | Supported |
| Automatic Nozzle Offset Calibration | Supported |
Dual AMS 2 Pro System
| AMS 2 Pro Units | 2 |
| Filament Slots per Unit | 4 |
| Total AMS 2 Pro Slots | 8 |
| Maximum Drying Temperature | 65°C |
| Automatic Spool Rotation | Supported |
| Active Moisture Discharge | Supported |
| RFID Filament Recognition | Supported |
| AMS 2 Pro Dimensions — Each | 372 × 280 × 226 mm |
| AMS 2 Pro Dimensions — Each | 14.65 × 11.02 × 8.90 in |
| AMS 2 Pro Net Weight — Each | 2.5 kg / 5.51 lb |
AMS HT
| AMS HT Units | 1 |
| Filament Slots | 1 |
| Maximum Drying Temperature | 85°C |
| Active Moisture Discharge | Supported |
| Automatic Spool Rotation | Supported |
| RFID Identification | Supported |
| Bypass Filament Outlet | Supported |
| Dimensions | 114 × 280 × 245 mm |
| Dimensions | 4.49 × 11.02 × 9.65 in |
| Net Weight | 1.21 kg / 2.67 lb |
Hotends Included in Ultimate Bundle
| 0.4 mm Induction Hotends | 7 total |
| 0.2 mm Induction Hotend | 1 |
| 0.6 mm Induction Hotend | 1 |
| 0.4 mm Standard Left Hotends | 2 |
| 0.2 mm Standard Left Hotend | 1 |
| 0.6 mm Standard Left Hotend | 1 |
| Total Hotends Supplied | 13 |
Supported Filaments
| Standard Materials | PLA, PETG, TPU, PVA and BVOH |
| Engineering Materials | ABS, ASA, PC, PA and PET |
| Composite Materials | Compatible carbon- and glass-fiber reinforced PLA, PETG, PA, PET, PC, ABS and ASA |
| High-Performance Materials | PPA-CF/GF, PPS and PPS-CF/GF |
| Filament Diameter | 1.75 mm |
Printer Dimensions & Weight
| Printer Dimensions | 492 × 514 × 626 mm |
| Printer Dimensions | 19.37 × 20.24 × 24.65 in |
| Printer Net Weight | 32.5 kg / 71.65 lb |
| H2C AMS Combo Gross Weight | 44.7 kg / 98.55 lb |
| Approx. Ultimate Bundle Shipping Weight | Approx. 112 lb |
Electronics & Connectivity
| Touchscreen | 5-inch color touchscreen |
| Network Connectivity | Wi-Fi |
| Offline Operation | Supported |
| Control Software | Bambu Studio |
| Mobile Control | Bambu Handy |
| Automatic Bed Leveling | Supported |
| Power-Loss Recovery | Supported |
Vortek Ultimate Bundle Configuration
| 3D Printer | Bambu Lab H2C |
| AMS 2 Pro | 2 units |
| AMS HT | 1 unit |
| Textured PEI Build Plate | Included |
| Spool Holder | Included |
| 4-in-1 PTFE Adapter II | Included |
| Accessory Box | Included |
| Additional Ultimate Hotends | 3 × 0.4 mm induction, 1 × 0.2 mm left, 1 × 0.6 mm left |
| Laser Module | Not included |
